PETROJET/Misr Petroleum Company-MPC

ESD Control system of Jet Fuel Storage Tanks at MPC Badr Field

  SIEMENS S7-400H Control System; Redundant IOs

  Fiber Optic Cables (60 Km)

  SCADA Video Wall Screen

 QTY: 2 Shelters

  Field Activities, Installation, Commissioning and Startup

PreviousNext

Egyptian Sugar & Integrated Industries Company

- DCS for Ethyl Alcohol Production Plant, ABU KURKAS factory

• Siemens DCS - PCS7 control system with redundant S7-400 hardware
• Process Instruments, Control valves, Pressure and Temperature gauges
• Hook up, Cables, Cable trays, .. etc.
• 2 Work stations – PCS7 - UPS
• Engineering, Commissioning & Startup

PreviousNext

Enppi / Badr Petroleum Company-Shell

- Design, Supply, Install, Commissioning and Startup of the ICSS for NEAG-1 field

• Integrated Control and Safety Systems (ICSS)
 Process Control System (PCS): High availability dual Hot redundant SIEMENS S7400H
 Emergency Shutdown System (ESD): High availability safety system SIL3, Dual hot redundant SIEMENS S7400FH, redundant fail safe I/O modules.
 Burner Management System (BMS): High availability safety system SIL3,Dual hot redundant SIEMENS S7400FH), Redundant fail safe I/O modules.
 SCADA: 8000 Tag, Redundant server, 50" Monitoring screen
 Industrial Dual Redundant UPS System: 30KVA, NICD batteries,Back up time 2 HR

• Pressurized Pre-fabricated control module that accommodate the ICSS
 IP 54 Pressurized shelter (18 x 6 x 4.2m L x W x H)
 Raised floor for cabling system
 false ceiling for lighting/fire/HVAC
 Explosion Proof Battery Room
 Fire Alarm and FM200 fire Fighting System for the shelter

• Central dual redundant Air conditioning system for the shelter.
